TYPE SW-RE (STRAIGHT WARP WITH REGULAR ELONGATION WEFT CORDS)

SW-RE conveyor belts, having a steel cable mesh, come in two variants: OIL RESISTANT which can be used in temperature range of -25ºC – 100ºC, or HEAT RESISTANT which can be used in a temperature range of -25ºC – 180ºC (max. 200ºC). Special steel cords gives the belts a good impact resistance, compression resistance, tensile strength and a favorable elongation. This category includes belts with elevator buckets and flat belts which may be subject to heavy loads due to materials with sharp edges.

Belt Widths and Edges

The widths are between 500-1600 mm for conveyor belts with moulded edges.

Type	SW 350	SW 500	SW 630	SW 800	SW 1000	SW 1250	SW 1400	SW 1600	SW 1800	SW 2000
Transversal tensile strength , N/mm	250	250	250	250	250	250	250	250	250	250
Mass, Kg/m2	2.45	3.10	3.60	4.55	5.40	6.50	7.25	8.10	8.75	9.30
Thickness, mm	4.6	4.6	4.6	5.4	5.4	6.3	6.3	6.3	6.3	6.3
Longitudinal tensile strength, N/mm	350	500	630	800	1000	1250	1400	1600	1800	2000
Warp cords	4x7x0.25 E		4x7x0.35 E				4x(0.50+6×0.44) E
Diameter, mm	2.0	2.0	2.0	2.85	2.85	3.90	3.90	3.90	3.90	3.90
Cord breaking strength – average, N – minimum, N	3250 3075	3250 3075	3250 3075	5900 5600	5900 5600	10100 9600	10100 9600	10100 9600	10100 9600	10100 9600
Elongation at break ,%	5	5	5	5	5	5	5	5	5	5
Density lin., g/m	11.4	11.4	11.4	22.9	22.9	37.9	37.9	37.9	37.9	37.9
-%Cu -%Zn	63.5 36.5	63.5 36.5	63.5 36.5	63.5 36.5	63.5 36.5	67.5 32.5	67.5 32.5	67.5 32.5	67.5 32.5	67.5 32.5
Pitch, mm	8.33	5.81	4.63	6.67	5.38	7.04	6.25	5.50	5.0	4.65
Cord density/m	120	172	216	150	186	142	160	182	200	215
Weft cords	3×0.60
Diameter mm	1.29	1.29	1.29	1.29	1.29	1.29	1.29	1.29	1.29	1.29
Cord breaking strength – average, N – minimum, N	1925 1775	1925 1775	1925 1775	1925 1775	1925 1775	1925 1775	1925 1775	1925 1775	1925 1775	1925 1775
Density lin., g/m	6.70	6.70	6.70	6.70	6.70	6.70	6.70	6.70	6.70	6.70
-%Cu -%Zn	67.5 32.5	67.5 32.5	67.5 32.5	67.5 32.5	67.5 32.5	67.5 32.5	67.5 32.5	67.5 32.5	67.5 32.5	67.5 32.5
Pitch, mm	6.67	6.67	6.67	6.67	6.67	6.67	6.67	6.67	6.67	6.67
Cord density/m	150	150	150	150	150	150	150	150	150	150

TYPE OF BELTS

MOR- conveyor belts with medium oil resistance.
G – conveyor belts with good oil resistance.
ROS – conveyor belts with very good oil resistance.
ST3- conveyor belts with high temperature resistance: (180ºC, maximum 200ºC)

Physical and mechanical characteristics	MOR	G	ROS
Tensile strength, kgf/cm², min.	150	150	150
Elongation at break, %, min.	450	450	450
Abrasion, mm3, max	160	160	150
Hardness ( ºSh A)	65±5	65±5	65±5
IRM 903 (21 days, 20ºC), ∆ V	+30	+30	+6
Working temperature, ºC	-25…+80	-25…+80	-25…+100

Physical and mechanical characteristics	Values (UKRB Standard)
Physical and mechanical characteristics	ST3
Tensile strength, kgf/cm², min.	120
Elongation at break, %, min.	350
Abrasion, mm³, max	250
Resistance to accelerated aging (168h at 150ºC)
– Decrease of the tensile strength % max.	60
– Decrease of the elongation at break % max.	80
– Increase of the hardness Sh A, max.	20
